XOP-7-OF Xenon Arc Lamp
XOP-7-OF 750W Xenon Arc Lamp, Replacement Light Bulb

Discontinued - No Remaining Stock - No Recommended Replacement

Lamps ordered will generally be shipped the next business day by USPS Priority Mail or UPS, check here for Shipping Information. Large orders may qualify for a discount and may not qualify for next day shipment. If you do not know what lamp you require or for lamps not listed, email your request or call 336-882-2854. To order, please use our secure shopping cart or call 336-882-2852 or 800-692-3051. Click to go to our Home Page and View Cart.

Wattage: 650-750W
Voltage: 52V
Amperage: 12.3A
Base: Double Ended Wire Leads
Bulb Diameter: .46"
Ceramic Cap Diameter: .64", 15.8x14.7mm
Maximum Overall Length: 243mm
Arc Gap: 160mm
Average Rated Life: 250-500 Hours
Color Temperature: 5600°K
Glass: Clear
Burn Position: Universal
Spectrum: 200-1000nm
No Ozone Production
Low Pressure Pulsed Xenon Discharge
Instant Start
Ignition Voltage: 10kV
Luminous Efficacy: 4.5 Lumens Per Watt
Lumens: 15,000-18,000
Tariff Code: 8539.41.00.00

Screening Required to Protect from Short Wave UV

Typical Use: DJ Lighting, Disco Strobe Light, Printing, Graphic Arts, Theimer KX8, Stroboscope Linear Xenon Flash Tube, Strobo

Alternate Part Numbers: Dr. Fischer 928376805102, XOP 7 O/F, 80604, Jenbo PS700, 191397, 9283 768 05102, 871150019139745, GE PXA-44, Ushio PXA44, GE 30119, Ushio UPX-44, UPX44, 5000262, 048777278017, 307504, XOP750, ST-750, ZB-750, 900126, BTX7, SX600, 1106-06, 1406-10 , 754-18026, AM633X, B1106-06, X202, 30750-4, OMLSL1000, Amba AM 633X, Theimer KX7 KX 7, Sylvania X202, 600W, 600 Watts Max, GE Flashtube, 9.5" Plus Ceramic Ends with Wire Leads, Xenon Pulsed Arc, Philips XOP7OF, XPA44, 18,000 Lumens, Graphic Arts, Theimer KX8, XOP-7

Addalux

750W

BEI

Powerflash, Power Flash, Model B750, B-750

Brown

Printing Lamp for 19642, 110606

Burgess

A1106A Strip Lights, Berkey, Pako, L1106A

Martin

Atomic 3000

NuArc

PXA-3000

Stroboscope

Golden Strobe

Techni-Lux

ST-ML504B-ML
ST-STROBE750
ST-STROBE750D
STROBE 750W
STROBE DMX 750W

Theimer

KX8

Tie Electronics

STARBURST 750 SERIES 750W

Cross reference information is designed to help you find the correct lamp for your application. We do not verify the accuracy of this information. You are responsible for ordering the correct lamp and we make every attempt to help you in that process. We recommend that you confirm the information with the equipment manufacturer before ordering.
